0-10V 225000lm 1500 Watt LED Stadium Lights For Sports Field IP65

Certification
China Shenzhen Sunrise Lighting Co.,Ltd. certification
China Shenzhen Sunrise Lighting Co.,Ltd. certification
I'm Online Chat Now

0-10V 225000lm 1500 Watt LED Stadium Lights For Sports Field IP65

0-10V 225000lm 1500 Watt LED Stadium Lights For Sports Field IP65
0-10V 225000lm 1500 Watt LED Stadium Lights For Sports Field IP65 0-10V 225000lm 1500 Watt LED Stadium Lights For Sports Field IP65 0-10V 225000lm 1500 Watt LED Stadium Lights For Sports Field IP65

Large Image :  0-10V 225000lm 1500 Watt LED Stadium Lights For Sports Field IP65

Product Details:
Place of Origin: Shen Zhen, China
Brand Name: SUNRISE
Model Number: SU-LS1500
Payment & Shipping Terms:
Minimum Order Quantity: 10 PCS
Price: Negotiated
Packaging Details: carton or customised
Delivery Time: 10-15 days
Payment Terms: T/T, Western Union, MoneyGram
Supply Ability: 20000pcs/month

0-10V 225000lm 1500 Watt LED Stadium Lights For Sports Field IP65

Description
Name: Dimmable Stadium LED Lights Lumen Flux: 225000lm
Color: 3000K, 4500K, 6500K Light Source: Philips SMD3030 Led
Material: Aluminum IP Rating: IP65 Waterproof
Driver Mode: Meanwell ELG Driver Surge Protection: 6KV
High Light:

225000lm sports field flood lights

,

1500W LED Stadium Light

,

1500 watt led stadium lights

0-10V Dimmable Stadium LED Lights 1500W 225000lm for Sport Fields IP65



Product Features of Dimmable Stadium LED Lights:

- The built-in upgraded 696 pcs super bright LED chips can produce 225000 high output brightness, which is much brighter than other light source.

- Up-cutting light visor stops the light ray scattering to the sky, reduce light waste. It can be moved away.

- Quick-installed laser sight, easily adjust the direction of illumination to achieve the max. lux and uniformity. Moreover, it can shorten the installation and layout time and save technician cost.

- Adopting high-density durable and strudy die-casting aluminum, strong structure, nice and stable performance as well as good heat dissipation.

- High efficiency PHILIPS driver / Tai Wan MeanWell driver.

- High quality Lumileds / Cree LEDs to 140-150lm/W.

- Single module 500w, smaller size, convenient installation and use for stadium sport sites.

- Waterproof protection IP65, able to work in wet and rain surroundings.

- IK08, 6KV-10KV surge protection.

- Passing the 4000v high voltage testing.

- Comparing to traditional metal halid lamps can save energy 70%-80%.

- No flash, no RF, no ultra violet radiation.

- Support mart function: 0-10V dimming, PMW signal, Timing optional, light sensor / Photocell and DMX512.



Product structure of Dimmable Stadium LED Lights:

1. Up-cutting visor:stop the upward light ray scattering,reducing light waste.
2. Optical PC lens,never yellowing.
3. Waterproof silicon ring,UV-resistant and reliable.
4. 3030/5050 SMD light source optional.
5. Aluminum base with high themal conductivity,fast heat sinking to reduce light decay.
6. Laser sight to minimize the installation time and lower labor cost.
7. ADC12 die-casting aluminum radiator,high efficiency up to 96W/M.K.
8. Breathing heat sink to prevent the sealing problems caused by thermal expansion and cold contraction
9. Aluminum case for singal external waterproof driver isolated to lamp body for longer lifespan of the lamp.



Product introduction of Dimmable Stadium LED Lights:

     This is the latest design with over-thick aluminum material and novel appearance for commercial or industrial lighting. The shell is pure die-cast aluminum with features of anti-pressure, high-strength, and anti-corrosion, and PC cover, waterproof IP65. It adopts constant current isolated MeanWell driver.



Parameters of Dimmable Stadium LED Lights:

SKU SU-LS1000 SU-LS1500 SU-LS2000
Input Voltage AC85-265V, 50/60Hz
Rated Wattage 1000W 1500W 2000W
Light Source SMD3030 Philips Chip Led
Product Dimension 665x603x574 665x885x811 1166x603x573
Luminous Flux 140-150lm/W
CCT 2700k, 3000k, 4500k, 6000k, 6500k
Body Material Die-cast Aluminum
Cover PC Lens 15°, 30°, 45°, 60°
CRI >80
PF >0.9
Surge Protection 6KV
Driver Mode Constant current driver
Driver Brand Meanwell ELG Driver
Beam Angle 15°, 30°, 45°, 60°
Work Temperature -40 ~ +50 Deg
Protection Class IK08 / IP65
Warranty 5 Years
Life Span 50,000 Hours
Control Mode 0-10V, DALI, RGBW, DMX512



0-10V 225000lm 1500 Watt LED Stadium Lights For Sports Field IP65 00-10V 225000lm 1500 Watt LED Stadium Lights For Sports Field IP65 1

0-10V 225000lm 1500 Watt LED Stadium Lights For Sports Field IP65 2

0-10V 225000lm 1500 Watt LED Stadium Lights For Sports Field IP65 3

0-10V 225000lm 1500 Watt LED Stadium Lights For Sports Field IP65 4



Dimension of of Dimmable Stadium LED Lights:

0-10V 225000lm 1500 Watt LED Stadium Lights For Sports Field IP65 50-10V 225000lm 1500 Watt LED Stadium Lights For Sports Field IP65 6



Details of Dimmable Stadium LED Lights:

0-10V 225000lm 1500 Watt LED Stadium Lights For Sports Field IP65 7



Structure figure of Dimmable Stadium LED Lights:

1. Up-cutting visor:stop the upward light ray scattering,reducing light waste.
2. Optical PC lens,never yellowing.
3. Waterproof silicon ring,UV-resistant and reliable.
4. 3030/5050 SMD light source optional.
5. Aluminum base with high themal conductivity,fast heat sinking to reduce light decay.
6. Laser sight to minimize the installation time and lower labor cost.
7. ADC12 die-casting aluminum radiator,high efficiency up to 96W/M.K.
8. Breathing heat sink to prevent the sealing problems caused by thermal expansion and cold contraction
9. Aluminum case for singal external waterproof driver isolated to lamp body for longer lifespan of the lamp.

0-10V 225000lm 1500 Watt LED Stadium Lights For Sports Field IP65 8















Installations of Dimmable Stadium LED Lights:

0-10V 225000lm 1500 Watt LED Stadium Lights For Sports Field IP65 9


Applications of Dimmable Stadium LED Lights:
    This light is widely used in stadium, tunnel, square, plaza, wharf, stadium, construction sites, stations, soccer, subway, metro, airport, sculpture, workshop, supermarkets and factory etc.
0-10V 225000lm 1500 Watt LED Stadium Lights For Sports Field IP65 10

Frequent Queations of High Mast LED Flood Lights:
1. Can I buy 1pc for test?
   Re: Yes, 1pc can be offered. Mixed trial order is welcome.

2. Can the high mast led flood light be dimmable?
   Re: Yes, it can be dimmable type made if required.

3. How long will you send out for 1pc?
   Re: 1 sample can be shipped within 3-5 days.

4. Can you make low voltage 24V, 36V?
   Re: Yes, we can have 12V, 24V, 36V and 48V.

4. Do you have different driver for this high mast led flood lights?
   Re: Yes, surely. The driver brand can be decided on your idea.

5. Can I move the laser sight away?
   Re: The laser sight is helpful when installation. If you don't need, it can be moved away.

6. How long will I get the goods?
   Re: For sample, we will send by express and it will takes about 5 days to deliver. For bulk quantity, we will send by sea or air. It will usually take 15-30 days to deliver.
