Outdoor 400W LED Adjustable Flood Light PIR Security Shockproof

Outdoor 400W LED Adjustable Flood Light PIR Security Shockproof
Outdoor 400W LED Adjustable Flood Light PIR Security Shockproof Outdoor 400W LED Adjustable Flood Light PIR Security Shockproof

Large Image :  Outdoor 400W LED Adjustable Flood Light PIR Security Shockproof

Product Details:
Place of Origin: Shen Zhen, China
Brand Name: SUNRISE
Model Number: SU-QP400
Payment & Shipping Terms:
Minimum Order Quantity: 10 PCS
Price: Negotiated
Packaging Details: normal carton size: 395x170x315mm or customised
Delivery Time: 10-15 days
Payment Terms: T/T, Western Union, MoneyGram
Supply Ability: 10000pcs/month

Outdoor 400W LED Adjustable Flood Light PIR Security Shockproof

Description
Name: LED Module Floodlight Size: 366*561*142MM
Packing Size: 590*375*200mm Lumen Flux: 48000lm
Feature: Corrion-proof, Shock-proof IP Rating: IP65 Waterproof
Light Source: SMD 3030 Philips Usage: Street, Tunnel Lighting
High Light:

400W adjustable pir security light

,

400W led adjustable flood light

,

adjustable outdoor flood lights shockproof

Philips 400W LED Module Floodlight for Tunnel Street Waterproof Lighting



Descriptions of LED Module Floodlight​:

    The LED module floodlight is adopted the integrated die-casting aluminum with high density, large heat dissipation area, and good thermal conductivity. The PC cover gets better light transmission, lame retardant and wear-resistant, strong oxidation resistance. The LEDs is made by single module, and each module is 100W. It can make 100w, 200w, 300w, 400w, 500w, and 600w. The Modules can be freely moved, so the installation is flexible and the bracket can be also adjusted as requested.



Product Features of LED Module Floodlight​:

►  Adopting high-density durable and sturdy die-cast aluminium, strong structure, nice and stable performance as well as good heat dissipation.

►  High efficiency Philips / MeanWell brand driver available.

►  High quality Lumileds / Cree / Philips Leds to 120-150lm/W.

►  Single module 100w, smaller size, convenient installation and use for stadium sport sites.
►  Waterproof protection IP65, able to work in wet and rain surroundings.
►  IK08, 6KV-10KV surge protection.
►  Passing the 4000v high voltage testing.
►  Comparing to traditional metal halid lamps can save energy 70%-80%.
►  No flash, No RF, No ultra violet radiation.
►  Support mart function: 0-10V dimming, Dali dimmer, PIR motion sensor, Light sensor / Photocell and DMX512, Remote Control.


Specifications of of LED Module Floodlight​:

Product Name LED Module Floodlight for Tunnel Streets
SKU SU-QP200 SU-QP300 SU-QP400
Product Dimension (mm) 366x311x142 366x436x142 366x561x142MM
Packing Size  (mm) 375x345x20mm 470x375x200mm 590x375x200mm
Input Voltage AC85-265V, 50/60Hz
Rated Wattages 200W 300W 400W
Lumen Flux 24000lm 36000lm 48000lm
Light Source SMD 3030 LED chips
Light Efficiency 120-150lm/W
CCT 2700, 3000k, 4500k, 6000k, 6500k (customised)
Body Material Die-cast Aluminum
Cover PC with lens
CRI >80
PF >0.9
Surge Protection 6KV
Driver Mode Constant current driver
Beam Angle 20°, 40°, 60°, 90°, 140x100° (optional)
Work Temperature -40 ~ +50 Deg
Protection Class IK07 / IP65
Warranty 5 Years
Control Mode 0-10V / Dali / RGBW



Dimension of Led Tunnel Lights:
