Product Details:
|
| Name: | LED Module Floodlight | Size: | 366*561*142MM |
|---|---|---|---|
| Packing Size: | 590*375*200mm | Lumen Flux: | 48000lm |
| Feature: | Corrion-proof, Shock-proof | IP Rating: | IP65 Waterproof |
| Light Source: | SMD 3030 | Usage: | Street, Tunnel Lighting |
| High Light: | 400W adjustable pir security light,400W led adjustable flood light,adjustable outdoor flood lights shockproof |
||
400W LED Module Floodlight for Tunnel Street Waterproof Lighting
Descriptions of LED Module Floodlight:
The LED module floodlight is adopted the integrated die-casting aluminum with high density, large heat dissipation area, and good thermal conductivity. The PC cover gets better light transmission, lame retardant and wear-resistant, strong oxidation resistance. The LEDs is made by single module, and each module is 100W. It can make 100w, 200w, 300w, 400w, 500w, and 600w. The Modules can be freely moved, so the installation is flexible and the bracket can be also adjusted as requested.
Product Features of LED Module Floodlight:
► Adopting high-density durable and sturdy die-cast aluminium, strong structure, nice and stable performance as well as good heat dissipation.
► High efficiency / MeanWell brand driver available.
► High quality Lumileds / Cree / Leds to 120-150lm/W.
Specifications of of LED Module Floodlight:
| Product Name | LED Module Floodlight for Tunnel Streets | ||
| SKU | SU-QP200 | SU-QP300 | SU-QP400 |
| Product Dimension (mm) | 366x311x142 | 366x436x142 | 366x561x142MM |
| Packing Size (mm) | 375x345x20mm | 470x375x200mm | 590x375x200mm |
| Input Voltage | AC85-265V, 50/60Hz | ||
| Rated Wattages | 200W | 300W | 400W |
| Lumen Flux | 24000lm | 36000lm | 48000lm |
| Light Source | SMD 3030 LED chips | ||
| Light Efficiency | 120-150lm/W | ||
| CCT | 2700, 3000k, 4500k, 6000k, 6500k (customised) | ||
| Body Material | Die-cast Aluminum | ||
| Cover | PC with lens | ||
| CRI | >80 | ||
| PF | >0.9 | ||
| Surge Protection | 6KV | ||
| Driver Mode | Constant current driver | ||
| Beam Angle | 20°, 40°, 60°, 90°, 140x100° (optional) | ||
| Work Temperature | -40 ~ +50 Deg | ||
| Protection Class | IK07 / IP65 | ||
| Ｗarranty | 5 Years | ||
| Control Mode | 0-10V / Dali / RGBW | ||
