IP65 IK07 LED Tunnel Lights SMD 3030 Die Casting Aluminum Eco Friendly
IP65 IK07 LED Tunnel Lights SMD 3030 Die Casting Aluminum Eco Friendly IP65 IK07 LED Tunnel Lights SMD 3030 Die Casting Aluminum Eco Friendly
Contact Now

IP65 IK07 LED Tunnel Lights SMD 3030 Die Casting Aluminum Eco Friendly

Minimum Order Quantity : 10 PCS Price : Negotiated
Packaging Details : normal carton size: 395x170x315mm or customised Delivery Time : 15-25 days
Payment Terms : T/T, Western Union, MoneyGram Supply Ability : 10000pcs/month
Place of Origin: Shen Zhen, China Brand Name: SUNRISE
Model Number: SU-QP200

Detail Information
Name: Module LED Tunnel Light Size: 366x311x42mm
Beam Angle: 20°, 40°, 60°, 90°, 140*100° Lumen: 120lm/W
PF: >0.9 IP Rating: IP65 Waterproof
Light Source: SMD 3030 Usage: Street, Road, Sport Fields
High Light:

IP65 led tunnel light IK07 SMD3030

,

IP65 IK07 Tunnel LED Lighting SMD3030

,

IK07 SMD3030 IP65 Tunnel LED Lighting

Product Description

Modular Led Tunnel Lights 100w 200w 300w 400w 500w 600w Waterproof IP65



Descriptions of Modular Led Tunnel Lights:

    The LED tunnel light is adopted the integrated die-casting aluminum with high density, large heat dissipation area, and good thermal conductivity. The PC cover gets better light transmission, lame retardant and wear-resistant, strong oxidation resistance. The LEDs is made by single module, and each module is 100W. It can make 100w, 200w, 300w, 400w, 500w, and 600w. The Modules can be freely adjusted, so the installation is flexible and the bracket can be also adjusted as requested.



Product Features of Modular Led Tunnel Lights:

►  Adopting high-density durable and sturdy die-cast aluminium, strong structure, nice and stable performance as well as good heat dissipation.

►  High efficiency / MeanWell brand driver available.

►  High quality Lumileds / Cree / Leds to 120-150lm/W.

►  Single module 100w, smaller size, convenient installation and use for stadium sport sites.
►  Waterproof protection IP65, able to work in wet and rain surroundings.
►  IK08, 6KV-10KV surge protection.
►  Passing the 4000v high voltage testing.
►  Comparing to traditional metal halid lamps can save energy 70%-80%.
►  No flash, No RF, No ultra violet radiation.
►  Support mart function: 0-10V dimming, Dali dimmer, PIR motion sensor, Light sensor / Photocell and DMX512, Remote Control.


Specifications of LED Tunnel Lights:

Product Name Module LED Tunnel Lights
SKU SU-QP100 SU-QP200 SU-QP300
Product Dimension (mm) 366x249x142 366 x311x142 366x436x142
Packing Size  (mm) 395x170x315 375x345x20mm 470x375x200mm
Input Voltage AC85-265V, 50/60Hz
Rated Wattages 100W 200W 300W
Light Source SMD 3030 LED chips
Luminous Flux 150lm/W
CCT 2700, 3000k, 4500k, 6000k, 6500k
Body Material Die-cast Aluminum
Cover PC with lens
CRI >80
PF >0.9
Surge Protection 6KV
Driver Mode Constant current driver
Beam Angle 20°, 40°, 60°, 90°, 140x100° (optional)
Work Temperature -40 ~ +50 Deg
Protection Class IK07 / IP65
Ｗarranty 5 Years
Control Mode 0-10V / Dali / RGBW





Dimension of Led Tunnel Lights:
IP65 IK07 LED Tunnel Lights SMD 3030 Die Casting Aluminum Eco Friendly 0
