Wharf Outdoor Waterproof Flood Light 26000lm IP66 200 Watt Flood Light LED

Minimum Order Quantity : 100 PCS Price : Negotiated
Packaging Details : normal carton or customised Delivery Time : 8-15 days
Payment Terms : T/T, Western Union, MoneyGram Supply Ability : 10000pcs/ctn
Place of Origin: Shen Zhen, China Brand Name: SUNRISE
Certification: CE, RoHS Model Number: SU-WS200

Detail Information

Name: Floodlights 200watts Material: Aluminum
LED Chip: Osram Smd 3030 Beam Angle: 60°
Usage: Construction Site, Wharf, Stadium Support Dimming: Yes
Cover: PC Cover Feature: Corrision-proof, Pressure-proof
High Light:

Wharf outdoor waterproof flood light

,

Wharf 26000lm 200 watt led outdoor light

,

Wharf 26000lm IP66 flood light led

Product Description

Waterproof IP66 Floodlights 200watts 26000lm For Outdoor Wharf Lighting

Quick details of Floodlights 200watts:
► Product type: Flood Lights.

► Model: SU-WS200.

► LED qty.: 240 PCS.

► Lumen index: 26000 lumens.
► Light source type: super bright LED chips SMD 3030 osram.
► Input work voltage: AC85-265V, 50/60Hz.
► Optional color temperature: normal 2700K, 3000K, 4500K, 6500K, 7000K+ and customised color.
► Available wattages: 30w, 50w, 100w, 150w and 200w.
► Surge protection: 4KV.
► Shock-proof class: IK07.
► Water-proof class: IP66.
► Material: die casting aluminum and optical PC lens with 60 Deg. and 120 Deg. optional.
► Optional narrow beam angle 60 degree and wide beam angle 120 degree.
► Various smart type: 0-10V dimming, Dali dimmming, pir motion sensor, radar sensor, photocel sensor, microwave sensor, DMX512 and remote control.

Descriptions of Floodlights 200watts:

► 240 LEDs 26000 Lumens
The built-in upgraded 240pcs super bright LED smd chips can make 26000lm high output brightness, which is much more brighter than other light sources.
► Brightness Upgraded
Powered by high-quality 3030 LED chips, increased the number of light beads, better brightness and large illumination.
► Thickened Aluminum
Superior & thickened ADC12# die-casting aluminum with corrosion-proof, shock-proof, dust-proof and weather-proof, faster heat sinking to keep long lifespan.
► Constant Current Driver
High quality constant current driver with high work efficiency, PF>0.9, famous brand drivers available.
► Waterproof Upgrated
Rain-proof & water-proof protection IP66 upgraded, suitable for wet applications.
► High Quality Glass Bead Cover
High-quality optical bead PC cover with 60 degree, no yellow, and high light transmission up to >95%.


Product Parameters of
Floodlights 200watts:

Product Name LED Floodlight 200watts
Model SU-WS100 SU-WS150 SU-WS200
Input Voltage AC85-265V, 50/60Hz
Power Consumption 100W 150W 200W
Light Source SMD 3030 Osram
Light Efficiency 130lm/W
Color Temperature 2700k, 3000k, 4500k, 5000k, 6500k
Product Size (mm) L284*W241*H40 L314*W272*H43 L344*W301*H43
Driver Constant Current Isolated Driver
Body Material ADC12 Aluminum
Cover Material PC cover
CRI >80
PF >0.9
Housing Color Black, White
Surge Protection 4KV
Beam Angle 60°
Class Protection IK07, IP66
Working Temperature: -30 ~ 50 Deg.
Life Span 50,000H
Warranty 3 Years
Application Square, Plaza, Construction Site, Mineral Estate, Supermarket, Wharf


Product Show of
Floodlights 200watts:
Wharf Outdoor Waterproof Flood Light 26000lm IP66 200 Watt Flood Light LED 0

Product figure of
Floodlights 200watts:

1. Optical PC lens against yellowing.
2. Waterproof silicon ring.
3. Nano-plastic reflector against the high temperature and UV, long use and never yellowing.
4. SMD3030 LED high light efficiency and lighting to further.
5. Aluminum base with high thermal conductivity,and faster heat running.
6. High-quality and famous brand driver: Meanwell, sosen etc.
7. ADC12 die-casting aluminum radiator, efficiency up to 96W/M.K.
8. Strong support and strong installation.
Wharf Outdoor Waterproof Flood Light 26000lm IP66 200 Watt Flood Light LED 1

Dimensions of
Floodlights 200watts:

Wharf Outdoor Waterproof Flood Light 26000lm IP66 200 Watt Flood Light LED 2
Wharf Outdoor Waterproof Flood Light 26000lm IP66 200 Watt Flood Light LED 3

Optical Lens 60 and 120 degree available of
Floodlights 200watts:
Wharf Outdoor Waterproof Flood Light 26000lm IP66 200 Watt Flood Light LED 4
Wharf Outdoor Waterproof Flood Light 26000lm IP66 200 Watt Flood Light LED 5


Installations of
Floodlights 200watts:
Wharf Outdoor Waterproof Flood Light 26000lm IP66 200 Watt Flood Light LED 6
Frequent Questions of
Floodlights 200watts:

1. Can I have 1pc sample to test firstly?
Re: Yes, 1pc sample can be offered, and mixed samples are welcome.


2. Do you have customised service like box, logo?
Re: Yes, all of our products can be customised. Please kindly tell us your idea!


3. Can you do Black body for this model?
Re: Yes, we can. This model has White and Black body for your options.


4. Can you make 120 degree for this floodlights 200watts?
Re: Yes, this model can make 60 degree and 120 degree.



5. Can the floodlights 200watts be dimmable?
Re: Yes, it supports to make dimmable like 0-10V, Dali dimming etc. Please contact us for details!

6. Can you design private carton box if I buy your goods?
Re: Yes, certainly. We often design and customise box for our clients. Please tell us your ideas and requests!

7. Does the floodlights 200watts include any driver?
Re: Yes, absolutely. This lamp includes constant-current isolated driver, PF>0.9 and warranty 3 years. Other brand driver is available.

8. How can you guarantee the quality?
Re: All raw materials must be checked before stocking and the finished products must have been tested and aged. Finally packed. If unfornately any fault happend, we will replace.
